Revit for Electrical Substation Projects

About this course

Vietnam's power sector is digitising rapidly, and BIM is becoming an expectation on substation projects. The civil scope of a substation covers the control building, transformer and equipment foundations, cable trenches, internal roads, gates and fencing, all of which must be modelled accurately to coordinate with the electrical disciplines.

This course from the RDSIC training centre of the Institute of Information Technology in Civil Engineering — Hanoi University of Civil Engineering (HUCE) teaches Autodesk Revit through the complete civil model of a real substation. Students start with the control building, build their own family library for foundations, equipment supports and cable trenches, then finish with rebar drawings, quantity schedules, printed deliverables and team collaboration skills.

What you will learn

• Model the architecture and structure of the control building: foundations, frame, walls, roof, doors and floors.
• Create custom families for transformer foundations, equipment support pedestals, gantry columns, cable trenches, fences, manholes and other substation components.
• Assemble the outdoor site model: roads, gates, retaining walls and kerbs from your own library.
• Place reinforcement in frames, foundations and roof slabs and present rebar drawings properly.
• Build schedules of components, materials and rebar for quantity take-off.
• Set up title blocks, print and export to DWG and IFC; collaborate through a central model and render with Enscape.

Who should enrol

• Civil engineers at electrical design consultancies.
• Technical staff of grid and substation project management boards.
• Revit users expanding into energy-sector industrial works.
• Power companies training teams to adopt BIM on their projects.

Detailed syllabus

1. BIM overview and project setup

• BIM concepts, pros and cons, workflow
• Revit interface and content installation
• Grids and levels for the control building
• Project base point, survey point and the two norths
• Structural columns and beams; frame completion exercise

2. Control building structure

• Structural floors and column stubs
• Isolated, strip and pile foundations
• Materials; completing the foundation and frame model

3. Walls and envelope

• Architectural walls: foundation, perimeter and partition walls
• Gable walls, parapets, gutters and wall-top ties
• Roof purlins by several methods

4. Roof, floors and architectural finishes

• Roofs with fascias, ridge caps and lightning rods
• Ground floors, yards and indoor trench openings
• Doors, windows and ventilation louvres
• Ramps, steps and thresholds

5. Model management tools

• Selection modes and view limits
• Hiding, isolating and 3D display control
• Keyboard shortcuts and productivity tools

6. Drawing production

• Architectural and roof framing plans
• Column setting-out, foundation plans and elevations
• Parameters and Project Browser organisation
• Sheets, legends and drafting views

7. Substation family library

• Family modelling principles in Revit
• Foundation families: isolated, strip, transformer, equipment pedestal, gantry, fence, lamp post and camera foundations
• Cable trench families (indoor and outdoor) with concrete and Cemboard covers; ceiling-hung cable trays
• Equipment support families: circuit breakers, surge arresters, disconnectors, CTs, VTs, post insulators, auxiliary transformers
• Gantry columns, lighting poles, spun concrete poles, lightning rods and drainage pipes
• Fences, gate pillars, sliding gates, retaining walls, kerbs, manholes and door types

8. Completing the outdoor site model

• Parameter tricks for later scheduling
• Troubleshooting common family problems
• Placing roads, gates, fences, retaining walls, kerbs, pedestals and trenches from the library
• Outdoor model completion exercise

9. Component and material schedules

• Schedules for walls, columns, beams, slabs and foundations
• Editing schedules and placing them on sheets
• Auditing the model so quantities come out right

10. Reinforcement and rebar drawings

• Rebar tools, bar types, covers and settings
• Rebar for frames, building and pedestal foundations, transformer foundations and roof slabs
• Rebar drawing presentation: visibility, line control, numbering, view templates, sections
• Rebar schedules and data formatting

11. Deliverables, collaboration and rendering

• Company-standard title blocks with data fields
• Printing, DWG and IFC export, reusable templates
• Links, shared coordinates, central models and worksets
• Rendering in Revit, in the cloud and with Enscape

12. Course wrap-up

• Reviewing the whole workflow, Q&A and guidance for applying it on each student's project

Learning format

The course is delivered in person in Hanoi in the evenings, with periodic intakes in Ho Chi Minh City and dedicated corporate classes for power companies. Every session pairs a lecture with hands-on practice on documents of a real substation.
