Civil 3D Course – Infrastructure & Road BIM

About this course

The Institute's 15-session Civil 3D course is built for infrastructure and road engineers who want to learn Civil 3D from survey data through to road design drawings and infrastructure BIM. Classes run live online over Zoom, with the instructor marking work in every session.

Autodesk Civil 3D is the core tool for infrastructure and highway engineers: it turns survey data into terrain surfaces, alignments, profiles, drainage networks and grading, with quantities updating automatically as the design changes. As BIM mandates for infrastructure tighten, these skills are a clear advantage.

This online course from the RDSIC training centre of the Institute of Information Technology in Civil Engineering — Hanoi University of Civil Engineering (HUCE) runs in two stages: ten sessions mastering Civil 3D from survey to deliverables, then five sessions on data management and BIM coordination covering BEP, the Common Data Environment and Navisworks, preparing students for both modelling and coordination roles.

Where to start with Civil 3D: the 15-session roadmap

The course follows the order in which a real road project is produced. Survey data comes first, because a terrain surface needs it. The surface comes next, because alignments and profiles are designed on it. The alignment comes before the corridor and the quantities. Learning Civil 3D in this order means each session reuses what the previous one produced.

The first ten sessions are about mastering the software. The last five are for those who will coordinate infrastructure models on BIM projects. To see how Civil 3D's dynamic model works before enrolling, read What is Civil 3D.

What do you need before learning Civil 3D?

The course does not teach the following from scratch, so students should already have:

• Basic AutoCAD: drawing, editing, layers, plotting. Civil 3D runs on AutoCAD, and students new to AutoCAD spend their effort on clicks instead of content. Without this foundation, take the AutoCAD course from beginner to advanced first.
• Road design knowledge at third-year highway or infrastructure student level: what profiles, cross sections, horizontal and vertical curves are. The course focuses on building them in Civil 3D.
• A computer that can run Civil 3D. No licence to buy: the Institute provides a time-limited educational licence to every learner, for learning use only; installation and minimum specs are in Install Civil 3D free for students.
• No Revit needed. Revit only appears in session 14, when surfaces and corridors are passed to other disciplines.

What you will learn

• Process survey point data, set up the VN-2000 coordinate system and manage large projects with Data Shortcuts.
• Build, refine and analyse terrain surfaces; design alignments and profiles to highway standards.
• Model corridors, resolve daylight slopes and junctions, and compute earthworks and pavement quantities.
• Design gravity drainage networks, run interference checks and export BOQ quantities.
• Grade sites with Feature Lines and Grading Objects, balancing cut and fill.
• Draft a BEP, run a CDE on Autodesk Forma and perform clash detection in Navisworks.

Who should enrol

• Road, infrastructure and water-resource engineers automating their design workflow.
• Engineers still drafting manually in 2D CAD who want to move to modelling.
• BIM Coordinators and Managers responsible for infrastructure scopes.
• Transport and urban infrastructure students preparing for employment.

Detailed syllabus

1. Project setup and survey data

• Optimising the Toolspace workspace
• VN-2000 coordinates and local unit conventions
• Importing, exporting and grouping survey points
• Sharing surfaces, alignments and networks across files with Data Shortcuts

2. Terrain surfaces and analysis

• Building surfaces from points, contours and text data
• Refining accuracy with breaklines and boundaries
• Slope, aspect and elevation analysis

3. Alignments and profiles

• Alignments with horizontal and transition curves to standard
• Design profiles and vertical curves
• Profile views, labels and data bands

4. Assemblies and corridors

• Building cross-sections from the subassembly library: carriageway, shoulders, footpaths, drains
• Corridor modelling with surface and width targets

5. Junctions, slopes and road quantities

• Corridor edits at junctions and curve widenings
• Complex cut and fill daylighting
• Sample lines and volume dashboards for earthworks and pavement

6. Drainage networks, basics

• Parts lists for gravity pipes and structures
• Laying out networks that follow existing ground

7. Advanced drainage and BOQ

• Hydraulic gradients on the profile
• Automatic pipe and manhole labels, interference checks
• Pipe length, manhole and trench excavation quantities

8. Grading with Feature Lines

• Creating and controlling characteristic elevation lines
• Fast, precise elevation editing commands

9. Grading objects and earthwork balance

• Graded areas, benching and slopes with Grading Objects
• Raising and lowering design surfaces to balance cut and fill

10. Drawing production

• Plan Production sheets: batch output of plans, profiles and cross-sections

11. Infrastructure BIM thinking and the BEP

• Benefits, challenges and Vietnamese regulations for infrastructure BIM
• Core BEP content for road and utility projects
• Naming, folder and layer conventions

12. The Common Data Environment

• Cloud data management principles
• Folders and role-based permissions on Autodesk Forma
• Review workflows, RFIs, issues and Autodesk Viewer

13. Multi-discipline models and LOD

• Splitting the federated model by discipline
• Base points and VN-2000 synchronisation across software
• LOD requirements for roads, drainage and landscape

14. Civil 3D to Revit coordination

• Bringing terrain and corridors into Revit with correct coordinates
• Converting pipe networks for high-LOD detailing of manholes, box culverts and overpasses

15. Quality control and clash detection

• Federating Civil 3D and Revit files in Navisworks or Forma
• Clash matrices and priorities
• Running detection, grouping issues and assigning them
• Coordination reports and final model review

Learning format

The course runs online over Zoom in 15 evening sessions with live instruction and homework review, plus support in the class group between sessions. Exercises follow the survey data and road documents of a real project.

Class photos and videos

Play video

Play video

Certificate of completion

Graduates receive a certificate from the Institute of Information Technology in Civil Engineering — Hanoi University of Civil Engineering (HUCE). Call 0989 427 809 or 0914 388 841 for upcoming schedules.

Frequently asked questions

Promotions and discounts

Group tuition discount — applied to every group member and the group leader:

Note: this discount cannot be combined with any other promotion.

Discounts for taking multiple courses at RDSIC

• Take two courses in parallel and get 10% off the tuition of each course.
• Your second course at RDSIC is 10% off.

Deferral policy

• In-person courses: deferral of up to one year from the date the centre confirms it.
• Online courses: no deferral; as an exception, students who have attended less than 50% of the course may be granted a deferral of up to one year.
